MicroHub InspectPro 4K Industrial Inspection Microscope

Overview

Inspection work needs numbers, not just a bigger picture. The InspectPro pairs a 4K camera and continuous-zoom lens with measuring software: calibrate once with the included ruler card, then read distances, radii and angles off the live image and save annotated captures for your QC records. The ring light's segmented control reduces glare on machined metal, and the post stand with XY stage makes repeatable part positioning practical. It is an inspection and documentation tool for workshops and production QC — not a substitute for certified metrology equipment where a certified measurement is contractually required.

Key benefits

• HDMI output. A live image on any monitor or TV — built for shared viewing, teaching and bench work.
• Image capture — 4K UHD camera (3840×2160). Save stills and video for records, teaching, listings or customer documentation.
• Working distance — Approx. 3–10 in (80–260 mm). The clearance under the lens decides whether hands and tools fit — this model publishes the figure.
• Focus — Autofocus assist with manual fine focus.
• Lighting — Segmented LED ring light, quadrant control, adjustable brightness.

Technical specifications

Magnification, explained honestly

For this model the published figure is: Approx. 12x–300x optical zoom (on a 27-inch monitor).

Two different things get called “magnification”. Optical magnification is produced by the lens system and carries real detail. Digital zoom enlarges the captured image on screen — the picture gets bigger, but no new detail appears, because the sensor captured a fixed amount of information. MicroHub publishes the derivation with every figure; where a headline number mixes the two, the optical range is the one to compare between models.

Working distance, screen & output

The working distance is the clearance between lens and subject — the space your hands and tools actually get. Screen and output decide who can watch: a built-in LCD for one pair of eyes at the bench, HDMI for a room, USB for capture and measurement.

What’s in the box

• InspectPro camera head and lens
• Measuring software license (download)
• LED ring light
• Post stand with XY stage
• Calibration ruler card
• HDMI and USB cables
• Power adapter
• Manual

Compatibility & power

Windows for full measurement software; HDMI live view on any monitor; basic USB view on Mac.

Power: AC adapter (included).

Who should buy this model — and who should not

Compare with alternatives

MicroHub ViewPro 10.1" LCD Digital Microscope
Big-screen 10.1-inch microscope with HDMI output for teaching and shared viewing
$1130.00 less than this model · Screen: 10.1-inch IPS LCD · Working distance 0.4–6 in

$169.99

View

MicroHub CoinView 7" Coin Microscope
Whole-coin view on screen, with HDMI for closer die and mint-mark study
$1180.00 less than this model · Screen: 7-inch LCD · Working distance 0.4–5.5 in

$119.99

View

MicroHub CoinView 7" Coin Microscope with Precision Scale
See it and weigh it: 7-inch coin microscope with a 0.001 g bench scale in the box
$1170.00 less than this model · Screen: 7-inch LCD

$129.99

View

Open the full comparison tool

Shipping, returns & warranty

Confirmed orders are prepared for dispatch within 2 business days, with standard US delivery typically in 3–7 business days after dispatch and tracking by email (shipping policy). Unused items in original condition can be returned within 30 days (returns & refunds). A 12-month warranty covers defects in materials and workmanship (warranty policy).

Frequently asked questions
