Binocular comfort for longer lab sessions, with a double-layer mechanical stage
Binocular viewing is the upgrade your eyes notice after twenty minutes: less strain, better depth judgment, and steadier fine focus. The LabBino pairs a Siedentopf binocular head with 10x and 20x eyepieces and four achromatic objectives, giving a true optical range of 40x to 2000x. The Abbe condenser with iris diaphragm and the double-layer mechanical stage are the features coursework actually uses — controlled contrast and repeatable slide positioning. This is an education and routine-lab microscope; it is not a clinical diagnostic instrument and does not replace certified medical laboratory equipment.
| Condenser | Abbe NA 1.25 with iris diaphragm and filter holder |
|---|---|
| Focus | Coaxial coarse and fine focus with tension adjustment |
| Head | Binocular Siedentopf, 30° inclined, interpupillary adjustment |
| Lighting | LED transmitted light, variable brightness |
| Magnification | 40x–2000x optical (10x and 20x eyepieces × 4x/10x/40x/100x objectives) |
| Objectives | Achromatic 4x, 10x, 40x (spring), 100x (spring, oil) |
| Power | AC adapter (included), 110–240 V |
| Stage | Double-layer mechanical stage, 4.9 × 4.9 in |
For this model the published figure is: 40x–2000x optical (10x and 20x eyepieces × 4x/10x/40x/100x objectives).
Two different things get called “magnification”. Optical magnification is produced by the lens system and carries real detail. Digital zoom enlarges the captured image on screen — the picture gets bigger, but no new detail appears, because the sensor captured a fixed amount of information. Focara publishes the derivation with every figure; where a headline number mixes the two, the optical range is the one to compare between models.
| Lighting | LED transmitted light, variable brightness |
|---|---|
| Focus | Coaxial coarse and fine focus with tension adjustment |
The working distance is the clearance between lens and subject — the space your hands and tools actually get. Screen and output decide who can watch: a built-in LCD for one pair of eyes at the bench, HDMI for a room, USB for capture and measurement.
Standalone optical instrument. Camera upgrade: pair with the Focara CamScope via a trinocular model instead.
Power: AC adapter (included), 110–240 V.
Your work is laboratory research, school science & stem, plant & specimen observation, and the specifications above — magnification, outputs and lighting — fit how you actually work. It is a intermediate-level instrument at a market-rate price of $339.99.
$159.99
View
$399.99
View
$39.99
ViewConfirmed orders are prepared for dispatch within 2 business days, with standard US delivery typically in 3–7 business days after dispatch and tracking by email (shipping policy). Unused items in original condition can be returned within 30 days (returns & refunds). A 12-month warranty covers defects in materials and workmanship (warranty policy).
40x–2000x optical (10x and 20x eyepieces × 4x/10x/40x/100x objectives). The figure is optical, produced by the lens system itself.
In the box: LabBino microscope; 10x and 20x eyepiece pairs; Immersion oil; Dust cover; Spare fuse and bulb kit; User manual. Standalone optical instrument. Camera upgrade: pair with the Focara CamScope via a trinocular model instead.
Checkout creates an order reference and an order email; we reply with confirmation and payment instructions — payment is not processed online yet. Unused items in original condition can be returned within 30 days, and the store's 12-month warranty covers defects in materials and workmanship.
